FOOD CANS
Round Three - Piece Tin Plate Cans - Printed/Plain
SPECIFICATION
| SL. NO |
CAN SIZES |
CAN HEIGHT in mm |
DESCRIPTION | ||
|---|---|---|---|---|---|
| IMPERIAL DIA |
METRIC in mm |
MINIMUM | MAXIMUM | ||
| 1 | 211 | 65 | 56 | 130 | Spices/Seeds etc. |
| 2 | 300 | 73 | 56 | 260 | Coffee powder/Energy drink/lubricants etc. |
| 3 | 301 | 75 | 56 | 139 | Baking powder, Vegetable seeds etc. |
| 4 | 307 | 83 | 56 | 130 | Energy drink powder/vegetable seeds etc. |
| 5 | 401 | 99 | 56 | 175 | Fruit pulp/Protein powder/Green pepper/other retort products etc. |
| 6 | 404 | 105 | 56 | 170 | Coffee powder/auto mobile spares etc |
| 7 | 603 | 153 | 120 | 260 | Pickled cucumber/Mushrooms/Milk powder/other retort products etc. |
| 8 | 700 | 175 | 120 | 260 | Mango pulp etc |
| 9 | 709 | 189 | 150 | 260 | Powder/Pulp etc. |
CLOSURE OPTIONS: Lids, Easy Open Ends (EOE), Penny Levers, Ring, Lid, Tagger (RLT)
BEVERAGE CANS
Round Three - Piece Tin Plate Cans
One Side Necked and Two Sides Necked Cans
SPECIFICATION
| SL. NO |
IMPERIAL DIA |
METRIC in mm |
NECKING DIAMETER in mm |
CAN HEIGHT in mm |
STD PACK VOLUME | DESCRIPTION | |
|---|---|---|---|---|---|---|---|
| TOP | BOTTOM | ||||||
| 1 | 202 | 52 | 200(50) | 202 | 104 | 180ml | Milk based beverages/Juices etc |
| 2 | 202 | 52 | 200(50) | 202 | 133 | 240ml | Milk based beverages/Juices etc |
| 3 | 202 | 52 | 200(50) | 200 | 56-165 | - | Milk based beverages/Juices/Seeds/Baking powder etc. |
CLOSURE OPTIONS: Easy Open Ends (EOE) option of Stay On Tab (SOT) and Ring Pull Tab (RPT) on one side and bottoms at other end.
Standard Pack Volume for Juices: Pack Volume of 180ml and 240ml
PROCESSED FOOD (OTS) CANS
Processed Food (OTS) Cans (Flattened & Built Up) for Fruit Pulps and Vegetables
SPECIFICATION
| TRADE NAME | in mm | in mm |
|---|---|---|
| No. 1 Tall | 73 x 116 | 300 x 409 |
| A 2 | 83 x 114 | 307 x 408 |
| A 2 1/2 | 99 x 119 | 401 x 411 |
| A 9 | 153 x 154 | 603 x 601 |
| A 10 | 153 x 178 | 603 x 700 |
| A 12 | 174 x 228 | 700 x 900 |
